SELF Mini channel product specifications | |
---|---|
Material | polymer concrete |
Length | 100 cm |
Width | 12 cm |
Height | 6 cm |
Weight | 6.3 kg |
Nominal width | 100 |
Joint formation | UNILINK®- Joint |
Clasp | Snap-in fastening |
Load capacity | Galvanised slotted grating cl. A15, cast grating cl. B125, plastic grating cl. B125 |
ANRIN UNILINK®-Joint


The optimised UNILINK® joint system eliminates the traditional differentiation between the beginning and end of the channel. Elements of an equal installation height can be joined in any arbitrary direction. The symmetrically divided half-joints enable the optional sealing of the splicing. Vertically aligned grooves and tongues support an efficient installation: In the process, the installation alignment can be chosen arbitrarily!
The flexibility in the design and installation phases enters a new dimension with the UNILINK® joint!
ANRIN Snap-in fastening

Decades of experience and detailed product development in the areas of assembly, maintenance and cleaning of drainage systems have produced impressive solutions for permanent fastening technologies.
ANRIN Snap-in fastenings are optimised for the specific load classes and unite reliability and high quality with functional design.
Accessorie for SELF Mini

End cap PP made of Polypropylene
grey
SELF Mini

End cap PP made of Polypropylene
black
SELF Mini
